Rahmegröße: M
Gabel: RockShox Domain R 29'' 15x110 170mm 44mm offset
Rahmen: NEW Overvolt 160mm travel integrated Bosch Supreme 5 alloy (UDH Dropout)
Stossdämpfer hinten: Lapierre Shock Metric 230x60mm
Lenkervorbau: Lapierre CNC, Ø: 31.8mm, L: 40mm (S/M), 45mm (L/XL)
Lenker: Lapierre alloy 6061DB, Width: 780mm, Rise: 15mm (S/M), Width: 780mm, Rise: 30mm (L/XL), Ø: 31.8mm
Griffe: Lapierre grips, S/M: small diameter, L/XL: large diameter
Umwerfer hinten: Shimano Deore RD-M5100, 11s
Schaltgriff: Shimano Deore SL-M5100 11s
Kurbelsatz: E13 E-spec+ alloy 160mm (S/M) / 165mm (L/XL) + E13 steel ring 34T
Kassette: Shimano Deore CS-M5100 11-51T 11s
Kette: KMC E11 Turbo 11s
Pedale: VP VPE-527
Bremse: Shimano M4100 4 pistons
Reifen vorne: Maxxis, front: 29x2.5 WT Assegai, 60TPI, EXO+, 3C MaxxGrip, TR / rear: 27.5x2.8 Minion DHR II 60TPI, EXO+, 3C Maxxterra, TR
Reifen hinten: Maxxis, front: 29x2.5 WT Assegai, 60TPI, EXO+, 3C MaxxGrip, TR / rear: 27.5x2.8 Minion DHR II 60TPI, EXO+, 3C Maxxterra, TR
Sattel: Selle Royal Vivo
Sattelstütze: Lapierre dropper, Ø: 31.6mm, travel 100mm (S), 130mm (M), 150mm (L/XL) + Shimano lever
Motor: BOSCH BES3
Batterie: LED Remote
Display: Led Remote
Felge hinten: Lapierre eAM+ 32H, front: 622x30 rear: 584x35 Tubeless Ready
Felge vorne: Lapierre eAM+ 32H, front: 622x30 rear: 584x35 Tubeless Ready
Nabe hinten: Lapierre DA210, 4 sealed bearings, boost 12x148, 32H Center Lock
Nabe vorne: Lapierre DA210, boost 15x110, 32H Center Lock


Geometriedaten:
Sitzrohr Länge (mm): 430
