Rahmegröße: M
Gabel: RockShox 35 Silver TK Air boost 15x110mm 29'' 140mm travel (e-MtB decals)
Fender compatible
Rahmen: New Overvolt FS 140mm Travel Integrated Bosch Supreme 5 alloy UDH Dropout + Kickstand & Fenders Ready
Stossdämpfer hinten: Lapierre metric 210x47,5mm
Lenkervorbau: Lapierre CNC, 0°, Ø: 31.8mm, L: 45mm (S/M), 50mm (L/XL)
Lenker: Lapierre alloy 6061DB, Width: 720mm (S/M) 740mm (L/XL), Rise: 15mm, Ø: 31.8mm
Griffe: Lapierre grips, S/M: small diameter, L/XL: large diameter
Umwerfer hinten: Shimano Deore RD-M5100, 11s Shadow +
Schaltgriff: Shimano Deore SL-M5100 11s
Kurbelsatz: Lapierre Overvolt ISIS 165mm (S/M) / 170mm (L/XL) + FSA Megatooth Chainring 38T
Kassette: Shimano Deore CS-M5100 11-51T 11s
Kette: KMC E11 Turbo 11s
Pedale: VP VPE-527
Bremse: Shimano M4100 4 (front) / 2 (rear) pistons
Reifen vorne: Schwalbe Johnny Watts 65-584, DD, Raceguard, 67EPI (27,5") (Front & Rear)
Reifen hinten: Schwalbe Johnny Watts 65-584, DD, Raceguard, 67EPI (27,5") (Front & Rear)
Sattel: Selle Royal Vivo Ergo Reflective
Sattelstütze: Lapierre dropper, Ø: 31.6mm, travel 100mm (S), 130mm (M), 150mm (L/XL) + Shimano lever
Motor: BOSCH BES3
Batterie: Intube battery 750Wh
Display: Led Remote
Felge hinten: Lapierre eAM+ 32H, 584x30C, Tubeless Ready
Felge vorne: Lapierre eAM+ 32H, 584x30C, Tubeless Ready
Nabe hinten: Lapierre DA210, 4 sealed bearings, boost 12x148, 32H, Center Lock
Nabe vorne: Lapierre DA210, 2 Sealed Bearing , boost 15x110, 32H, Center Lock


Geometriedaten:
Sitzrohr Länge (mm): 430
